Edgetech 2050-DSS User Manual

4-53
=
4.9.3 Cable A309183 Layback Chart
2050-DSS WITH CABLE A309183 (MAX. WORKING LOAD = 44.0 KN)
Cable Paid Out (m) Speed (kts) Speed (m/s) Depth Achieved (m) Max Cable Tension (N)
500 2.00 1.03 400 4,551
500 4.00 2.06 228 4,393
500 6.00 3.09 153 6,044
500 8.00 4.12 115 8,984
1,000 2.00 1.03 761 7,672
1,000 4.00 2.06 431 7,504
1,000 6.00 3.09 292 10,826
1,000 8.00 4.12 220 16,575
2,000 2.00 1.03 1,475 13,864
2,000 4.00 2.06 836 13,725
2,000 6.00 3.09 569 20,391
2,000 8.00 4.12 429 31,760
4,000 2.00 1.03 2,899* 26,223
4,000 4.00 2.06 1,648 26,167
4,000 6.00 3.09 1,124 39,525
4,000 8.00 4.12 849 62,146**
*Max depth rating of 2,000m exceeded
**Max working load of 44.0 kN exceeded
Table 4-7: Cable A309183 Layback Chart
