3.2.2 Starmux IV 2050 Rack Mount Controls, Indicators, and Connections
In addition to the standard Starmux IV controls and I/O functions, the rack-mounted system is coupled
with a computer system and additional I/O as described below.
FRONT PANEL CPU
USB Connectors
(2) USB connectors.
DVD Drive
DVD\RW drive.
CPU Power and Reset
Computer Power and Reset Switches and Indicators.
BACK PANEL CPU
Line VAC Connector
CEE-type AC input connector.
Power Switch
Rocker switch. Turns the 2U-CPU computer on or off.
USB Connectors (4) USB connectors
Ethernet Connectors RJ-45 connectors
Video card
Video card with 4 Mini DP (Display)Connectors
COM-1 NAV Connector
DB-9 female connector. RS-232 serial port that connects to the navigation
system.
COM-3 Connector DB-9 female connector. General-purpose RS-232 serial port.
Table 3-5: Starmux IV Rack Mount Controls, Indicators, and Connections
