Edgetech 2050-DSS User Manual

4-51
=
4.9.1 Cable A320327 Layback Chart
2050-DSS WITH CABLE A320327 (MAX. WORKING LOAD = 17.1 KN)
Cable Paid Out (m) Speed (kts) Speed (m/s) Depth Achieved (m)
Max Cable
Tension (N)
500
2.00
1.03
404
2,065
500
4.00
2.06
219
1,873
500
6.00
3.09
141
2,117
500
8.00
4.12
103
2,688
1,000 2.00 1.03 718 2,790
1,000 4.00 2.06 376 2,466
1,000
6.00
3.09
246
2,945
1,000
8.00
4.12
182
3,946
2,000
2.00
1.03
1,307
4,164
2,000 4.00 2.06 688 3,648
2,000
6.00
3.09
457
4,602
2,000
8.00
4.12
341
6,464
4,000
2.00
1.03
2,466*
6,873
4,000
4.00
2.06
1,313
6,012
4,000 6.00 3.09 879 7,915
4,000
8.00
4.12
659
11,499
*Max depth rating of 2,000m exceeded
Table 4-5: Cable A320327 Layback Chart
