Figure 3-9: Labeled Rear Picture of 2050 Rackmount
USB Connectors
AC Fuse
Sea Cable Connector
Data Ethernet Connector
Grounding
Lug
Power
Switch
Power Switch
Ethernet Connectors
Video Card
PC COM-1
PC COM-3
FSK Sync
Connector
Fuse
