SECTION 3: SETUP AND INSTALLATION 3-2
The status reply indicates one of four states:
• "upright (within 45° of upright)" and released
• "upright (within 45° of upright)" and not released
• "tilted (more than 45° from upright)" and released
• "tilted (more than 45° from upright)" and not released
After a command has been received, the unit transmits a series of encoded pings. The 4 possible status
replies are:
PATTERN STATUS
15 pings at 2 second intervals
Upright ; Not Released
7 pings at 2 second intervals
Tilted ; Not Released
15 pings at 1 second rate
Upright ; Released
7 pings at 1 second rate Tilted ; Released
Table 3-1: Status Reply Meanings
