SECTION 5: MAINTENANCE 4-20
Figure 4-28: On/Off Actuator Plug on the Clevis End
Figure 4-29: The ON and OFF Positions of the On/Off Actuator Plug
On/Off Instructions
Turning the On/Off Actuator On and Off is extremely simple. If this option was purchased, follow the
instructions below. If this option was not purchased, disregard this section, as the On/Off Actuator Plug
was replaced with a Dummy Plug.
Note: When powered on, the On/Off Actuator Plug is approximately flush
with the End Cap and the epoxy retainer is wrapped around the .19-inch
diameter stub, as shown in FIGURE 4-29.
