SECTION 5: MAINTENANCE 4-10
Figure 4-15: Use the Mallet to Ensure the Lifting Support is Securely Attached
CAUTION!
The load capacity is less than 1/10 the rated load if the two 1/2 in. (1.27
cm.) diameter x 4 in. (10 cm.) spreaders are not installed in the cage. The
horizontal members of the cage must form a complete box.
CAUTION!
Ensure the Nylon washers are included in the reassembly procedure and
are placed between the titanium washer and the Support Brackets. They
are vital to the operation of the 8242XS. Refer to FIGURE 5-9.
3. Start by replacing the two titanium bolts on the two sides of the top cage-clamp assembly. Replace
the bolts with only one nut first as shown in F
IGURE 4-16.
Figure 4-16: Replace the Two Titanium bolts
