Edgetech 8242XS - Figure 4-25: Rotating the Shaft Using the Arming Wrench

4-17
3. Using the slotted arming tool, rotate the shaft clockwise until the internal mechanism ‘clicks’ and
holds position. DO NOT FORCE THE MECHANISM FURTHER THAN NEEDED (approximately 40-inch-
pounds torque is required to rotate the shaft 30 degrees clockwise).
CAUTION!
The Release Mechanism is armed after rotating the shaft. Do not attempt
reverse rotation with the arming tool. Forced reverse rotation will
jeopardize optimum performance.
Figure 4-25: Rotating the Shaft Using the Arming Wrench
