Edgetech 8242XS - 0002650 Bom; Table 5-4: 0002650 BOM

5-21
0002650 BOM
This table depicts the Material Call outs in FIGURE 5-18: 8242XS RELEASE SUB ELECTRONICS RELEASE ASSEMBLY
– 0002650.
QTY
DESCRIPTION
EDGETECH MTL NUMBER
1
HOUSING PRESSURE 8202 / 8242 MACHINED & PAINTED 20 INCH NAB 6000M
MTL 1
2
WELDMENT 8242 LIFTING SUPPORT ASB
MTL 2
2
CLAMP END CAP 8242 MACHINED HEAT TREATED
MTL 3
2
O-RING BUNA-N 70 2-245 STANDARD ROUND BLACK
MTL 4
2
O-RING BUNA-N 70 2-240 STANDARD ROUND BLACK
MTL 5
2
O-RING BUNA-N 90 8-240 BACKUP PARBAK ROUND BLACK
MTL 6
1
ANODE 8242 XS 2.36 INCH 1.75 INCH ZINC
MTL 7
1
HARDWARE BOLT STD MACHINE HEX HD 5/16-18 1.75 INCH TI
MTL 8
4
HARDWARE BOLT STD MACHINE HEX HD 5/16-18 2.25 INCH TI
MTL 9
10
HARDWARE WASHER STD SHOULDER 0.3125 INCH 0.75 INCH BARREL NYLON
MTL 10
10
HARDWARE WASHER STD FLAT 0.3125 ID 0.75 OD 5/64 THICK TI
MTL 11
10
HARDWARE NUT STD HEX 5/16-18 TI
MTL 12
2
BUSHING INSULATOR 8242 XS 0.07 THICK DELRIN
MTL 13
1
BRACKET TOP 8242 SUPPORT PVC
MTL 14
2
BRACKET CART BATTERY HOLD DOWN AL
MTL 15
1
BRACKET 8242 PCB / BATTERY AL
MTL 16
1
BATTERY PACK 8242 XS ALKALINE
MTL 17
4
HARDWARE SCREW STD MACHINE PAN HD PHILLIPS 6-32 0.3125 INCH 18-8 SS
MTL 18
8
HARDWARE WASHER STD FLAT 06 LP 18-8 SS
MTL 19
8
HARDWARE WASHER STD SPLIT LOCK 06 18-8 SS
MTL 20
2
SPACER 8242 LIFTING SUPPORT G-10 FIBERGLASS
MTL 21
2
LABEL EDGETECH
MTL 22
1
HARDWARE WASHER STD INSULATING 0.25 INCH NYLON
MTL 23
2
HARDWARE SCREW STD MACHINE FLAT HD 100 PHILLIPS 6-32 0.375 INCH 300 SS
MTL 24
1
LABEL SERIAL NUMBER EDGETECH
MTL 25
1
TIE CABLE SELF-LOCKING 356MM 18LB NYLON ROHS
MTL 26
4
HARDWARE SCREW STD PAN HD PHILLIPS 6-32 0.50 INCH 18-8 SS
MTL 27
6
HARDWARE SCREW STD MACHINE PAN HD PHILLIPS 4-40 0.3125 INCH 18-8 SS
MTL 28
6
HARDWARE WASHER STD SPLIT LOCK 04 18-8 SS
MTL 29
6
HARDWARE WASHER STD FLAT 04 SP 18-8 SS
MTL 30
.63 ft
TAPE SPONGE STRIP / STICK 01 INCH 1/16 INCH
MTL 31
Table 5-4: 0002650 BOM
