0002780 BOM
This table depicts the Material Call outs in FIGURE 5-20: 8242XS RELEASE MECHANISM SUB ASSEMBLY – PAGE 1
OF
2 – 002780 and FIGURE 5-21: 8242XS RELEASE MECHANISM SUB ASSEMBLY – PAGE 2 OF 2 – 002780.
QTY DESCRIPTION
EDGETECH MTL
NUMBER
1
PLATE MOUNTING LOWER 8242 AL
MTL 1
1
SHAFT DRIVE 8242 XS 303 SS
MTL 2
1
ARM PIVOT 8242 AL
MTL 3
1
PLATE 8242 RE-ARM CONTACT 303 SS
MTL 4
1
PLATE 8242 RE-FLAG AL
MTL 5
1
PLATE MOUNTING 8242 MOTOR AL
MTL 6
1
ARM 8242 RELEASE AL
MTL 7
1
SPRING REWORK
MTL 8
1
PLATE MOUNTING 8242 XS BATTERY AL
MTL 9
1
MOTOR RELEASE CART / 8242XS
MTL 10
1
END CAP LOWER 8242 W/ CLEVIS MACHINED NAB 6000M
MTL 11
1
HOOK RELEASE 8242 MACHINED NAB 6000M
MTL 12
1
LATCH 8242 XS LUBRICATED NSB 6000M
ASM 13
1
PIN 8242 CLEVIS HOOK NAB 6000M
MTL 14
1
PIN 8242 RELEASE LATCH NAB 6000M
MTL 15
2
O-RING BUNA-N 70 2-014 STANDARD ROUND BLACK
MTL 16
1
DUMMY PLUG 8242 DIAGNOSTICS PORT NAB
MTL 17
1
LATCH 8242 XS SWITCH ACTUATOR G-10 6000M
MTL 18
2
HARDWARE SCREW STD PAN HD PHILLIPS 8-32 0.3125 INCH NYLON
MTL 19
1
PLUG PURGE 8242 NAB 6000M
MTL 20
1
PLUG RETAINER 8242 G10 FIBERGLASS
MTL 21
1
NUT 8242 CLEVIS HOOK PIN HEX 5/8-11 NAB
MTL 22
1
NUT 8242 RELEASE LATCH PIN HEX 3/8-16 NAB
MTL 23
2
O-RING BUNA-N 70 2-008 STANDARD ROUND BLACK
MTL 24
.01OZ
LUBRICANT AQUA SHIELD
MTL 25
1
SPRING MAIN RELEASE MECHANISM
ASM 26
2
SWITCH SNAP-ACTION SPDT 05 AMP 250 VAC ROHS
MTL 27
1
ACTUATOR TANDEM LEAF W/ROLLER
MTL 28
1
CONN INLINE 0.100 INCH HOUSING 04 POS FEMALE ROHS KK WITH RAMP SINGLE ROW
POLARIZED
MTL 29
4
CONTACT FEMALE CRIMP 22-30 AWG GOLD ROHS
MTL 30
1
HARDWARE STANDOFF STD MALE / MALE 1/4-20 X 0.370 INCH MACHINED 303 SS
MTL 31
2
HARDWARE STANDOFF STD ROUND MALE / MALE 1/4-20 0.375 INCH DIA 1.50 INCH
LENGTH AL
MTL 32
3
HARDWARE STANDOFF STD HEX F/F 0.375 INCH HEX 01 INCH LENGTH AL
MTL 33
2
O-RING BUNA-N 70 2-110 STANDARD ROUND BLACK
MTL 34
1
O-RING BUNA-N 70 2-115 STANDARD ROUND BLACK
MTL 35
1
RETAINER 8242 O-RING NAB
MTL 36
1
HARDWARE SCREW STD SET SOCKET HD HEX 8-32 0.375 INCH 18-8 SS CUP POINT
MTL37
1
SHAFT T-RELEASE LUBRICATED
MTL380
.01OZ
LUBRICANT ANTI-SEIZE THREAD COMPOUND 70% MOLYBDENUM DISULFIDE
MTL 39
