5-17
General Inspection and Replacement Schedule
This chart is for customer convenience and gives general guidelines for inspection and suggested
replacement times for key parts. Regular inspections and cleaning are vital and should be done in tandem.
Table 5-1: General Inspection and Replacement Schedule
Field Service Kit
QTY
DESCRIPTION
EDGETECH MTL NUMBER
1
ANODE 8242 XS 2.36 INCH 1.75 INCH ZINC
MTL 1
8
HARDWARE BOLT STD MACHINE HEX HD 5/16 18 2.25 INCH TI
MTL 3
20
HARDWARE WASHER STD FLAT 0.3125 ID 0.75 OD 5/64 THICK TI
MTL 4
2
HARDWARE BOLT STD MACHINE HEX HD 5/16 18 1.75 INCH TI
MTL 5
20
HARDWARE NUT STD HEX 5/16 18 TI
MTL 6
2
ASSY TOP LINK ANCHOR 8242 RELEASE
MTL 7
4
ASSY TOP KIT SPARES BACS O RING
ASM 8
1
LUBRICANT GREASE SILICONE
MTL 9
20
HARDWARE WASHER STD SHOULDER 0.3125 INCH 0.75 INCH BARREL NYLON
MTL 10
2
PLUG RETAINER 8242 G10 FIBERGLASS
MTL 12
1
LATCH 8242 XS SWITCH ACTUATOR G 10 6000M
MTL 13
4
HARDWARE SCREW STD PAN HD PHILLIPS 8 32 0.3125 INCH NYLON
MTL 14
6
BUSHING INSULATOR 8242 XS 0.07 THICK DELRIN
MTL 15
2
SPACER 8242 LIFTING SUPPORT G 10 FIBERGLASS
MTL 16
1
PLUG PURGE 8242 NAB 6000M
MTL 17
Table 5-2: Field Kit – 0003102
Callout Assembly Drawings
Callout Assembly Drawings for the 8242XS are shown below.
PART
SERVICE / INSPECTION
REPLACEMENT
NOTES
O-ring
Before and After Each
Deployment
As needed
Any questionable O-ring should be immediately replaced.
EdgeTech recommends the use of Parker Super O-lube silicone
compound grease.
Battery Pack
Before Each Deployment
As needed
Release Hook
Before and After Each
Deployment
As needed
Release Link Before Each Deployment Per release
The Release Link is sacrificial and must be replaced after each
deployment. The Release Link is not sacrificed in Tandem
Assemblies.
Release Shaft
O-Ring
As needed Check after 3-5 years Contact EDGETECH CUSTOMER SERVICE for replacement
Anode After Each Deployment As needed
The anode should be replaced if chipped, damaged, or has
degraded significantly from its original size.
Purge Port
Retainer
Before and After Each
Deployment
Should not be
needed
