Edimax CV-7428nS User Manual

12
Note: If the Wi-Fi network you wish to connect to is
not listed, try clicking “Refresh” to refresh the list.
6. Click “NEXT” to continue, and Internet Explorer and Firefox users will be
asked to confirm if you wish to add “http://edimax.go” to your bookmarks.
We recommend that you do so for future use.
Note: If you are using a different browser, it is
recommended that you copy the URL
“http://edimax.go” and add it to your bookmarks
manually.
7. Next, please wait while the wireless bridge tests the connection.
8. When the test has finished, the following screen will be displayed. Please
click “NEXT” to continue.

Edimax CV-7428nS Specifications

Power

power adapter voltage	DC 5V
power adapter current	1A

Operating Environment

humidity	10-90% (Non-condensing)
temperature range	0-40°C
temperature range in Fahrenheit	32 - 104°F

Wireless Standards

frequency band	2.4 GHz
IEEE 802.11n data rate	up to 300Mbps
IEEE 802.11g data rate	up to 54Mbps
IEEE 802.11b data rate	up to 11Mbps

Ports & Interfaces

LAN ports	5 x RJ-45
antenna type	2 x 2dBi external antennas
LED indicators	Power, Wireless, LAN ports

Weight and Dimensions

weight	155 grams
height	30 mm
width	127 mm
depth	96 mm
