Edwards ModuLaser User Manual

ModuLaser Modular Aspirating Smoke Detector Installation Manual 11
Chapter 2
Installation
Summary
This chapter provides detailed installation and connection information for your
detector.
Caution: This product must be installed and maintained by qualified personnel
adhering to all local or national installation requirements and any other applicable
regulations.
Content
Electrical safety 12
Installation 12
Overview 12
Module and PCB layout 14
Backplane installation 17
Connections 20
Recommended cables 20
Connecting modules 21
Connecting pipes 32
Connecting to a PC 33

Edwards ModuLaser Specifications

General

Brand	Edwards
Model	ModuLaser
Category	Smoke Alarm
Language	English
