Chapter 3: Configuration and Commissioning
ModuLaser Modular Aspirating Smoke Detector Installation Manual 39
Configuration options
The options listed below are available when making configuration changes.
Table 8: Configuration controls
Description
Saves the current configuration change without applying it
immediately.
Note: When making configuration changes to legacy devices, the
changes are saved by pressing F1 (Apply).
1 Applies the current configuration change and all stored (saved)
configuration changes. The detector resets automatically.
2 Discards the current configuration change and returns to the previous
screen.
3 Exits the configuration process without storing or applying the current
configuration change. The configuration process can be resumed.
Notes
• Configuration changes are only applied to the system by pressing F1 (Apply).
• When updating multiple configuration settings, we recommend that you save
after each change, and then apply all changes from the Main menu.
• Only values within the allowed range for each parameter will be accepted.
• Any changes not applied are lost when the system exits a restricted user
level.
Wizards
Wizards are provided to assist maintenance and configuration tasks. Access
restrictions for each are shown below.
Access level
Access level 2 and higher
Access level 3 and higher
The maintenance wizard
To use the maintenance wizard:
1. Press F1 (Wizard) from the Main menu.
2. Select Maintenance Wizard.
3. Press F3 (Next) to step through the menus included in the wizard (see
Table 9 on page 40).
Press Enter to access a menu. From a menu, press F2 (Back) to return to the
wizard.
