ModuLaser Modular Aspirating Smoke Detector Installation Manual 87
Chapter 5
Technical specifications
Power supply
Supply voltage
18 to 30 VDC, 24 VDC nominal
21.2 to 27.2 VDC, 24 VDC nominal (UL/cUL
and FM)
Current consumption (at 24 VDC)
Detector module
Minimum display module
Command, standard display module
260 mA (fan speed 1)
380 mA (fan speed 6)
940 mA (fan speed 16)
204 mA
232 mA (display backlight off)
Communications
Display connectivit
y USB and APIC
Data bus length (RS
-485)
SenseNET+
SenseNET
1,200 m (4,000 ft.) max. between nodes or
modules
1,200 m (4,000 ft.) max. length (sum of all
single cable sections)
Inputs and outputs
I
nputs
Number of inputs
End-of-line resistance
2
15 KΩ 5% 1/4 W
Outputs
Number of outputs
Contact type
Resistive load
3
C/NO/NC, voltage free
2 A at 30 VDC
