Chapter 3: Configuration and Commissioning
40 ModuLaser Modular Aspirating Smoke Detector Installation Manual
4. When you have completed the required maintenance tasks, press F2 (Exit) to
exit the wizard.
Table 9: The maintenance wizard
Menu
Description
Enable/
Disable Disable devices before starting maintenance. See
“Disabling a device” on page 52 for more information.
Filter Status
Display the filter status for detectors. We recommend that
the filter is changed when the F
ilter value reaches 20% (this
indicates an 80% filter blockage). See “Detector status” on
page 42 for more information.
Input Test
Test inputs. See “Performing an input test” on page 50 for
more information.
Output Test
Test outputs. See “Performing an output test” on page 50
for more information.
Enable/Disable
Enable devices previously disabled for maintenance.
The configuration wizard
To use the configuration wizard:
1. Press F1 (Wizard) from the Main menu.
2. Select Configuration Wizard.
3. Press F3 (Next) to step through the menus included in the wizard (see
Table 10 below).
Press Enter to access a menu. From a menu, press F2 (Back) to return to the
wizard.
4. Press F3 (Apply) to apply configuration changes, and then press F2 (Exit) to
exit the wizard.
Table 10: The configuration wizard
Menu
Description
Network Setup
Scan the network to find devices. See “Configuring the
network” on page 67 for more information.
Date and Time
Configure date and time settings See “Changing the date
and time” on page 54 for more information.
Alarm Levels
Configure alarm level settings for detectors See
“Configuring the alarm levels” on page 62 for more
information.
Flow Setup
Configure flow limit values, fan speed, and power save
settings for detectors See “Configuring flow parameters”
on
page 66 for more information.
Inputs
Configure input settings See “Configuring the inputs” on
page 56 for more information.
