Chapter 3: Configuration and Commissioning
ModuLaser Modular Aspirating Smoke Detector Installation Manual 43
Description
Detection aborted Indicates that the detection is aborted.
FastLearn mode Indicates that the detector is in FastLearn mode. This mode is
used to learn the current smoke level present in the
environment.
Intermediate learn
mode
Indicates that the detector is in intermediate learn mode. In this
mode, the detector is partially operational while it is fine tuning
the environment learning.
Normal mode Indicates that the detector mode of operation is normal.
Flow setup Indicates that flow setup is in process.
Pipe calibration Indicates that pipe calibration is in process.
Day mode Indicates that the primary sensitivity mode setting for the
detector is day mode.
Night mode Indicates that the primary sensitivity mode setting for the
detector is night mode.
Table 12: Status screen values
Description
2 The Fire Alarm 2 smoke threshold (percentage)
The Fire Alarm smoke threshold (percentage)
The Prealarm smoke alarm threshold (percentage)
The Alert/Aux. Alarm smoke threshold (percentage)
The detector output level (percentage)
The filter cleanliness level (percentage)
The flow measured for the detector (lpm or cfm)
The flow high limit (lpm or cfm)
The flow low limit (lpm or cfm)
Spd The fan speed (1 to 16)
Table 13: Status screen banner messages
Displays Priority [1]
Displays when detection is aborted 1
2] Displays during a Fire Alarm 2 state 2
2] Displays during a Fire Alarm state 3
2] Displays during a Prealarm state 4
2] Displays during an Alert/Aux. Alarm state 5
