Chapter 3: Configuration and Commissioning
ModuLaser Modular Aspirating Smoke Detector Installation Manual 45
Description
Configures the time format (12-hour or 24-hour).
Configures automatic daylight saving (Europe, US, Australia, or
Manual).
To localize the display:
1. Select General Settings from the Main menu, and then select Localization.
2. Select the option that you want to configure, and then enter your changes.
3. Press F1 (Save) to save your changes and exit to the previous screen.
4. If you have no other configuration changes to make, then press F1 (Apply)
from the Main menu or the submenu to apply the changes to the system.
Changing screen properties
Use the Screen Properties menu to configure screen properties, such as
brightness and backlight mode. Configurable options are shown in the table
below.
Table 15: Screen property options
Description
Configures the brightness of the display.
Configures the display backlight mode (Auto, Always On). Select
Always On if the display should be permanently lit (even after an
automatic logout).
Configures the functionality of the F3 soft key for the home screen
available options are: Unused (no F3 soft key functionality), Reset
(resets all devices in the system), Disable (open the Disable menu),
and Test (opens the Test menu).
Configures the automatic timeout period (in minutes) to exit a restricted
access level if no keys are pressed.
The display backlight is turned off when the timeout period elapses and
the system logs out. Any configuration changes that have not been
applied are lost after the timeout period.
Configures the power save feature. If Power Save is checked, the
display enters low power mode and turns off after 90 seconds of
inactivity when a mains fault is detected.
[1] For access levels 1 and 2, backlight brightness is reduced after half of the configured timeout
value.
