4.3 Unpack and inspect

WARNING:

Use suit

able liing equipment to move the nXDS pump. The maximum pump mass is

27 kg.

Mechanical liing equipment should be aached to the liing eye; Loose slings

should not be used.

Take care when moving the pump into posion. Its mass may make it dicult to slide.

The fan cowl is shaped to provide a handhold for posioning; the pump must not be

lied using this handhold.

Remove all packing materials, remove the pump from its packing box, remove the

protecve covers from the inlet and outlet ports and inspect the pump. If the pump is

damaged, nofy the supplier and carrier in wring. State the item number of the pump

together with the order number and supplier's invoice number. Retain all the packing

materials for inspecon. Do not use the pump if it is damaged. If the pump is not to be

used immediately, replace the protecve covers. Store the pump in the condions

described in Storage on page 47. Refer to Disposal on page 47 for disposal of materials.

4.4 Posion the pump

WARNING:

If the pump is t

o be used on the oor of a work area, posion the power lead and the

exhaust and inlet hoses with care. Ensure that personnel in the area are aware of any

obstrucons around the pump.

Provide a rm, level plaorm for the pump. Locate the pump so that the gas ballast

control and the user controls are accessible.

If the pump will be located inside an enclosure, ensure that there is adequate venlaon

at both ends of the pump, so that the ambient temperature around the pump does not

exceed 40 °C. There must be a minimum space of 25 mm between the pump and the

enclosure walls.

4.4.1 Mechanical xing

Note:

The pump c

an be secured by using the four holes located on each corner of the pump

base. We recommend you to use M8 bolts.

Page 27

A73501880_G - Installaon

Edwards nXDS15i User Manual
