Note:
If c
onnecng the exhaust lter onto the pump outlet, an NW25 / hose nozzle, C10514328
is available to connect onto the outlet of the dust lter.
Table 20
Inlet/exhaust lter
Product descripon
Ordering informaon
Inlet/exhaust lter NW25/NW25 A50597805
9.2.6 Exhaust nozzle
The e
xhaust nozzle screws into the outlet ange. Use the exhaust nozzle to connect the
pump to the 12 mm internal diameter plasc hose.
Table 21
Exhaust nozzle
Product descripon
Ordering informaon
Exhaust nozzle A50509000
9.2.7 Chemical resistance conversion kit
This adaptor kit allows a standard nXDS pump to be converted into an nXDSC version.
This conversion may be necessary if the pump is used on applicaons involving corrosive
substances. For more informaon, contact us.
Note:
If re
turning the pump to us for repair or service having been converted from a standard
version to an nXDS
C version, our service must be informed, otherwise the pump will be
returned back as a standard version.
Table 22
Chemical resistance conversion kit
Product descripon
Ordering informaon
Chemical adaptor kit for nXDS 6i, 10i or
15i
A73501807
Chemical adaptor kit for nXDS20i A73501808
9.2.8 Electrical cables
Refer to Table: Electrical cables on page 51. The following electrical cables are available
as accessories and should be used to connect the nXDS pump to the electrical supply.
Table 23
Electrical cables
Product descripon
Ordering informaon
Lead Assembly, 10 A, C13, UK A50505000
Lead Assembly, 10 A, C13, Europe A50506000
Lead Assembly, 10 A, C13, USA A50507000
Lead Assembly, 10 A, C13, No Plug A50508000
Page 51
A73501880_G - Spares and accessories
