Descripon Rang
Coupler type Item number
Plug Type = European Schuko VDE
appr
oved, 16 A 250 V rated with dual
earthing contact
Appliance Coupler = IEC60320 style C14 N/A
Cord set
assembly,
USA/Canada
Cable style = SJT, 3 x 18 AWG, 300 V,
70 °C, VW‑1 maximum length of
2.0 metres
Straight entry A50507000
Plug Type = NEMA, 5‑15P plug
Appliance Coupler = IEC 60320 style C14
3.5 Logic interface data
The pumps have a 15‑way D‑type logic interface connector located on the user interface
panel (Figure: nXDS scroll pump on page 11, item 7). The logic interface connector can
be plugged directly into the 200 W Turbo Instrument Controller (TIC) or Turbo Controller,
or Turbo and Acve Gauge controller (TAG). A suitable connector mang half must be
used (not supplied) to connect the nXDS pump to the customer control system. Refer to
Table: Logic interface technical data on page 21 for the interface technical data and
Table: Logic interface connector pins on page 22 for the logic interface pins for the
electrical connecons.
Table 11
Logic interface technical data
Logic interface descripon
Connector* 15‑way D‑type (male)
Start, serial enable and remote enable:
Enable control voltage: low
(closed)
0 to 0.8 V d.c. (l
OUT
= 0.55 mA nominal)
Disable control voltage: high
(open)
4 to 26.4 V d.c. (Internal pull up to 6.4 V
nominal)
Standby control input:
Enable control voltage: low
(closed)
0 to 0.8 V d.c. (l
OUT
= 0.3 mA nominal)
Disable control voltage: high
(open)
4 to 26.4 V d.c. (Internal pull up to 3.2 V
nominal)
Analogue and RS485 enable control inputs:
Enable control voltage: low
(closed)
0 to 0.8 V d.c. (l
OUT
= 0.55 mA nominal)
Disable control voltage: high
(open)
4 to 52.8 V d.c. (Internal pull up to 6.4 V
nominal)
Analogue speed input
0 to 10 V d.c. directly proporonal to the
motor speed e.g. 0 V = 0 Hz, 10 V = 30 Hz
Voltage accuracy ± 5% full scale
NORMAL status output:
Page 21
A73501880_G - Technical data
