© Edwards Limited 2012. All rights reserved. Page 5
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
M561-00-880 Issue C
2Technical data
2.1 General technical data
Table 1 - General technical data
Pump
Characteristics
Body dimensions
Length x Width x
Height
(excludes exhaust
enclosure)
*
Mass
(excluding
packaging)
Noise level
(at ultimate)
Typical
vibration
level at inlet
Initial force
to push the
pump
Sustained
force to push
the pump
Pump inlet
flange
(bolted)
Exhaust gas
outlet
Extraction
port
diameter
Units mm kg dB(A) mm/s kg force kg force mm
iXH100 784 x 390 x 526 260 < 70 < 1.5 < 20 < 4 ISO63 NW40 105
iXH200H 901 x 390 x 526 287 < 70 < 1.5 < 20 < 4 ISO63 NW40 105
iXH450H 1000 x 517 x 650 455 < 70 < 1.5 < 20 < 10 ISO63 NW40 105
iXH500H 1000 x 517 x 650 490 < 70 < 1.5 < 20 < 10 ISO63 NW40 105
iXH610 784 x 390 x 780 355 < 70 < 1.5 < 20 < 4 ISO100 NW40 105
iXH1210/H 784 x 390 x 780 413 - 430 < 70 < 1.5 < 20 < 4 ISO100 NW40 105
iXH1220H/T 901 x 390 x 780 455 - 460 < 70 < 1.5 < 20 < 4 ISO100 NW40 105
iXH1820/H/T 901 x 390 x 780 471 - 487 < 70 < 1.5 < 20 < 4 ISO160 NW40 105
iXH3030/T 915 x 517 x 966 619 - 624 < 70 < 1.5 < 20 < 10 ISO160 NW40 105
iXH3045H 1000 x 517 x 966 776 70 < 1.5 < 20 < 10 ISO160 NW40 105
iXH3050H 1000 x 517 x 966 811 70 < 1.5 < 20 < 10 ISO160 NW40 105
iXH4545HT 1000 x 517 x 966 814 70 < 1.5 < 20 < 10 ISO200 NW40 105
iXH4550HT 1000 x 517 x 966 849 70 < 1.5 < 20 < 10 ISO200 NW40 105
iXH6045H/T 1080 x 517 x 966 860 - 865 74 < 1.5 < 20 < 10 ISO250 NW40 105
iXH6050H/T 1080 x 517 x 966 899 70 < 1.5 < 20 < 10 ISO250 NW40 105
pXH4500 1086 x 517 x 531 400 < 70 < 1.5 < 20 < 10 ISO200 ISO160 -
pXH6000 1086 x 517 x 531 435 < 70 < 1.5 < 20 < 10 ISO250 ISO160 -
iXL250Q 1092 x 390 x 830 515 <64 <1.5 <20 <10 ISO160 NW40 105
iXL500Q 1186 x 517 x 966 860 < 70 < 1.5 < 20 < 10 ISO160 NW50 105
iXL500R 1186 x 517 x 966 874 < 70 < 1.5 < 20 < 10 ISO160 NW50 105
