© Edwards Limited 2012. All rights reserved. Page 63
Edwards and the Edwards logo are trademarks of Edwards Limited.
Appendix A1
M561-00-880 Issue C
For systems which contain an iXH or iXL connected to a pXH, it is important to connect the PDT to the iXH or iXL if
you wish to configure the iXH or iXL IP settings and to connect the PDT to the pXH if you wish to configure the pXH
IP settings.
A1.4.9 Display attributes menu
Under the Setup menu. Scroll by pressing up/down keys. Press ENTER to open a sub menu or CANCEL to exit back to
the Setup menu.
SELECT LINE (Normal display selection menu)
Scroll by pressing up/down keys. Press ENTER to open a sub menu or CANCEL to exit back to the Display
Attributes menu.
In each option the SELECT PARAMETER menu is opened, scroll through the parameters by pressing up/
down keys. Press ENTER to select the parameter for display or CANCEL to exit back to the SELECT LINE
menu.
UNITS (Units to display)
Scroll by pressing up/down keys. Press ENTER to open a sub menu or CANCEL to exit back to the Display
Attributes menu.
In each option scroll through the units available by pressing up/down keys. Press ENTER to select the displayed units
or CANCEL to exit back to the UNITS menu.
Note: The configuration options for the PDT are stored in the PDT itself and are not associated with the pump
that the PDT is connected to. This means a user can transfer a PDT between pumps and keep the same
settings. It also means that different units could be displayed on two PDTs connected to the same pump.
Table A12 - Display attributes menu
Normal display (Selects the parameters displayed in Normal)
Units…
Table A13 - SELECT LINE (Normal display selection menu)
Top Page 1…
Bottom Page 1…
Top Page 2…
Bottom Page 2…
Table A14 - UNITS (Units to display)
Pressure... (PSI/kPa)
Temperature... (Centigrade/Farenheit)
Speed... (RPM/Hz)
Active Gauge... (mBar/Torr/kPA)
