Technical data
M561-00-880 Issue C
Table 13 - Water consumption data
Pump
Characteristics
Min flow rate required
(for low temp operation)
Typical water flow rate
*
*
Water consumption varies with pump operating temperature and water temperature; these figures measured
at factory default internal pump temperature, 15°C water inlet temperature and ultimate inlet pressure.
Rated Min Pressure Differential
†
†
The TMS is a valved system and the ‘Rated Min Pressure Differential’ may not correlate with water flow
rates stated in the table under all operating conditions. The ‘Rated Min Pressure Differential’ is required to
maintain adequate cooling water flow under adverse operating conditions.
Units l/min l/min bar
iXH100 22 1
iXH200H 42.7 1
iXH450H 66 1.25
iXH500H 66 1.25
iXH610 43 1
iXH1210 54 1
iXH1210H 64.2 1
iXH1220H/T 74.7 1
iXH1820 64.2 1
iXH1820H 74.7 1
iXH1820T 6 3.5 1
iXH3030 87 1.5
iXH3030T 88 1.5
iXH3045H 12 11 2
iXH3050H 12 11 2
iXH4545HT 12 11 2
iXH4550HT 12 11 2
iXH6045H/T 12 11 2
iXH6050H/T 12 11 2
pXH4500 66 1.25
pXH6000 66 1.25
iXL250Q 7 61
iXL500Q 12 11 2
iXL500R 12 11 2
iXL750Q 10 92.5
iXL750R 10 92.5
