Appendix A1
A1.4.3 SETUP menu
Press the Setup button to enter. Menu title is shown at the top of the display. Scroll by pressing up/down keys. Press
ENTER to open a sub menu or CANCEL to exit back to Normal menu.
Each sub menu is described below.
pXH Booster speed in Hz PB SPEED 100 Hz
Dry Pump Inverter Temperature DP INV TEMP 100C
Booster Inverter Temperature MB INV TEMP 100C
pXH Booster Inverter Temperature PB INV TEMP 100C
Dry Pump Exhaust pressure EXHAUST 5 PSI
Dry Pump Exhaust Temperature EXH PIPE 100C
Dry Pump Exhaust gas temperature EXH TEMP 100C
Active gauge pressure AG 1.1E-3 kPa
Water Flow Rate WATER 11.1 l/m
Run Hours RUN HOURS 1000
pXH Run Hours PB RUN HOURS 1000
Number of Pump Starts PUMP STARTS 100
Time to Stop (seconds) TIME TO STOP 900
Active Alarms and Warnings (if present)
*
The PDT returns the serial number of the system it is plugged directly into. For example, if an iXH is being
used to control a pXH, the PDT can be plugged into either system. If it is plugged into the iXH, it returns the
serial number of the iXH and if it is plugged into the pXH it returns the serial number of the pXH.
All warning and alarm codes from the iXH dry pump and booster are in the range 101.01 to 799.15.
All warning and alarm codes from the pXH booster are in the range 801.01 to 899.15.
Table A6 - SETUP menu
Description Display
Commands menu
*
Command Menu…
Display Inverter Fault History menu Inv Fault Hist…
Software Version Display menu S/W Version…
Display Serial Number Serial Num…
Fit Accessory menu
*
*
This option requires a security code to access it.
Fit Accessory…
Edit IP configuration menu IP Config…
Edit Display attributes menu Display Attr…
Set Time and Date
†
†
Time is set automatically when connected to a Fabworks network.
Set Clock…
Display Pump Type Show Pump type...
