Technical data
2.3 Loading data
Table 4 - Loading data (refer to Figure 5)
Pump
Dimension to centre of gravity Load at levelling foot position
ABCDE1234
Unitsmmmmmmmmmm kg kg kg kg
iXH100 697 295 165.5 311 280 80 59 51 70
iXH200H 814 403 165.5 311 261 77 76 66 68
iXH450H 924 443 220 427 323 122 112 106 115
iXH500H 924 422 220 427 324 137 115 109 129
iXH610 697 329 165.5 311 374 100 89 78 88
iXH1210/H 697 330 165.5 311 430 122 106 94 108
iXH1220H/T 814 457 165.5 311 430 107 136 120 94
iXH1820/H/T 814 400 165.5 311 433 134 127 112 118
iXH3030/T 829 395 230 436 545 183 147 131 164
iXH3045H 924 422 220.5 427 534 218 183 171 203
iXH3050H 924 409 220 427 524 233 185 174 219
iXH4545HT 924 422 220.5 427 539 228 192 180 214
iXH4550HT 924 411 220.5 427 529 243 195 183 228
iXH6045H/T 1004 398 220.5 427 549 269 177 166 252
iXH6050H/T 1004 388 220.5 427 539 285 179 168 267
pXH4500 990 460.5 225 438 325 110 96 90 104
pXH6000 990 422 224.5 438 326 128 95 90 122
iXL250Q 1038 421 130.5 261 463 154 103 103 154
iXL500Q 1110 497 219 427 468 212 172 164 202
iXL500R 1110 497 219 427 468 241 195 185 229
iXL750Q 1547 730.9 169 338 512.2 215 244 244 215
iXL750R 1547 722.1 169 338 534.6 229 259 259 229
