M561-00-880 Issue C
Page 10 © Edwards Limited 2012. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
Note: If you are not sure which gas module is fitted to your system, find the product code number on the label on the rear of the pump and then refer to the
product configurators at the start of this manual.
Note: H variant pumps fitted with Single Mode+ modules include the innovative Gas Buster
TM
inlet purge for improved powder handling.
For iXL systems:
iXL systems are designed for use on clean applications only.
Table 6 - Gas module types and flows
For iXH systems:
Gas module
type
Description
Module
sizes
available
Total flow,
harsh
setting
Total flow,
medium
setting
Total flow
with inlet
purge
Total flow
with
exhaust
purge
Total flow
with inlet
and exhaust
purge
Units
Loadlock Shaft seal only 4 4 - - - - -
Single mode
Gas ballast purge with harsh/medium
manually selected
44 44 28 - - - slm
96 96 56 - - - slm
133 133 88 - - - slm
204 204 133 - - - slm
Single mode +
Gas ballast purge with harsh/medium
manually selected + inlet purge
44 44 28 60 - - slm
96 96 56 122 - - slm
133 133 88 173 - - slm
204 204 133 264 - - slm
Multi mode
Gas ballast purge with electronically selected
harsh/medium + inlet purge + exhaust purge
44 44 22 60 94 110 slm
96 96 34 122 146 172 slm
133 133 65 173 183 223 slm
204 204
*
*
Contact Edwards
264 254 314 slm
