Edwards pXH6000 User Manual

© Edwards Limited 2012. All rights reserved. Page 61
Edwards and the Edwards logo are trademarks of Edwards Limited.
Appendix A1
M561-00-880 Issue C
A1.4.4 COMMANDS menu
Under the Setup menu. Scroll by pressing up/down keys. Press ENTER to open a sub menu or CANCEL to exit back to
the SETUP menu.
Press the up/down keys to select the new settings and press ENTER to accept or CANCEL to exit back to the
COMMANDS menu.
A1.4.4.1 GAS VALVES menu
Scroll by pressing up/down keys. Press ENTER to open a sub menu or CANCEL to exit back to the Setup menu. Settings
do not appear if they are not fitted.
Press the up/down keys to select on / off and press ENTER to accept or CANCEL to exit back to the GAS VALVES
menu.
A1.4.5 INV FAULT HIST (Display Inverter Fault History) menu
Under the Setup menu. Scroll by pressing up/down keys. Press ENTER to open a sub menu or CANCEL to exit back to
the Setup menu.
Each inverter fault history contains up to 32 entries, each contains one alarm and one warning, where 1 is the most
recent. Scroll by pressing up/down keys. Press CANCEL to exit back to the Inverter Fault History menu.
The inverter fault information is displayed in the following format:
DP Inv Fault nn
A:aaaa W:wwww
where nn is the number, aaaa is the alarm code, and wwww is the warning code.
Refer to Section A2.3 for more information about inverter warnings and alarms.
Table A7 - COMMANDS menu
Gate Valve (Open/Shut)
*
*
This option requires a security code to access it.
MB Pump (On/Off)
†
†
The PDT must be in control to perform these functions.
PB Pump (On/Off)
†
Green Mode (On/Off)
†
Green Level (Idle/Sleep/Hibernate/Mode4..8)*
Gas Valves
*
Table A8 - GAS VALVES menu
Set N
2
Seal
Set Inlet 1
Set Bypass
Set Exhaust 2
Table A9 - INV FAULT HIST (Display Inverter Fault History) menu
DP Inv Fault Hist (Dry Pump Inverter Fault History)
DP2 Inv Fault Hist (Dry Pump 2nd Inverter Fault History)
MB Inv Fault Hist (Booster Inverter Fault History)
PB Inv Fault Hist (pXH Booster Inverter Fault History)
