© Edwards Limited 2012. All rights reserved. Page 73
Edwards and the Edwards logo are trademarks of Edwards Limited.
Appendix A2
M561-00-880 Issue C
The following text will be displayed if the condition is SELFTEST_WARNING, SELF_TEST_FAULT_, or
EEPROM_FAULT____.
Table A20 - Inverter diagnostic display text
Inverter
diagnostic
Register 1
Inverter
diagnostic
Register 2
Text display
0x8000 0x0000 INTERNAL_COMMS__
0x4000 0x0000 P_CHARGE_WARNING
0x2000 0x0000 WATCHDOG_TIMEOUT
0x1000 0x0000 OSTEST_FAULT____
0x0800 0x0000 EEPROM_LOW_VCC__
0x0400 0x0000 EEPROM_WRITEFAIL
0x0200 0x0000 EEPROM_TIMEOUT__
0x0100 0x0000 EEPROM_BYTECOUNT
0x0080 0x0000 FLASH_BOOT_CRC__
0x0040 0x0000 FLASH_WRITE_FAIL
0x0020 0x0000 FLASH_BLOCK_CRC_
0x0010 0x0000 EXTERNAL_RESET__
0x0008 0x0000 SINK_TEMP_FAULT_
0x0004 0x0000 CAL_DATA_INVALID
0x0002 0x0000 EEPROM_BLOCK_CRC
0x0001 0x0000 EEPROM_MAP_ID___
0x0000 0x0200 IGBT_OPEN_CCT___
0x0000 0x0100 MOTOR_OPEN_CCT__
0x0000 0x0010 MOTOR_SHORT_CCT_
0x0000 0x0008 VOLTAGE_SENSOR__
0x0000 0x0004 CURRENT_SENSOR__
0x0000 0x0002 IGBT_OPEN_CCT___
0x0000 0x0001 IGBT_SHORT_CCT__
0x8000 0x0000 INTERNAL_COMMS__
0x4000 0x0000 P_CHARGE_WARNING
0x2000 0x0000 WATCHDOG_TIMEOUT
0x1000 0x0000 OSTEST_FAULT____
0x0800 0x0000 EEPROM_LOW_VCC__
