EFKA FP220A5911
3
CONTENTS Page
1 Important Safety Instructions 7
2 Range of Applications 8
2.1 Use in Accordance with Regulations 9
3 Scope of Supply 9
3.1 Special Accessories 10
4 Use of the C200 Compiler 11
5 Connection of Stepping Motor Controls to the FP220A Control 12
5.1 SM210A Control Settings for Operating the FP220A Control 12
5.2 FP220A Control Settings 12
6 Control Operation without Control Panel 13
6.1 Access Authorization upon Command Input 13
6.2 Programming the Code Number 14
6.3 Parameter Selection 15
6.3.1 Direct Selection 15
6.3.2 Changing Parameter Values 16
6.3.3 Parameter Selection with the +/- Keys 17
6.3.4 Immediate Storage of All Changed Data 17
6.4 Changing All Parameter Values at the Operator Level 18
6.5 Function Switchover 18
6.6 Direct Input of Maximum Speed Limitation without Control Panel 18
6.7 Program Identification on the Control 19
7 Control Operation with Control Panel 20
7.1 Operation of the V810 Control Panel 20
7.1.1 Code Number Input on the V810 Control Panel 20
7.1.2 Parameter Input at the Operator Level on the V810 Control Panel 20
7.1.3 Parameter Input at the Technician/Supplier Level on the V810 Control Panel 21
7.2 V820 Control Panel Operation 21
7.2.1 Code Number Input on the V820 Control Panel 21
7.2.2 Parameter Input at the Operator Level on the V820 Control Panel 22
7.2.3 Parameter Input at the Technician/Supplier Level on the V820 Control Panel 22
7.3 Program Identification 23
7.4 Direct Input of Maximum Speed Limitation (DED) with Control Panel 23
7.4.1 Setting on the V810 Control Panel 23
7.4.2 Setting on the V820 Control Panel 23
7.5 Keys for Background Information (HIT) with V820 24
7.5.1 Example of HIT 24
7.5.2 Further Functions of the V810/V820 Control Panels 25
7.5.3 Special Functions of the V820 Control Panel 26
7.6 Programming of Seams (TEACH IN) 27
7.6.1 Programming after Code Number Input 28
7.6.2 Programming without Code Number Input 28
7.6.3 Detailed Example 30
7.6.4 Inserting a Seam or Pattern 31
7.6.5 Deleting a Seam or Pattern 32
7.6.6 Execution (Pattern) Mode 32
7.6.7 Further Settings for TEACH IN 32
8 Putting into Service 34
9 Setting and Putting into Service with the Aid of the Fast Installation Routine (SIR) 34
