EFKA FP220A5911
81
The ON periods can be selected separately for signal A1 by means of parameter 305 and for signal A2 by means of
parameter 315.
The speed mode can be set separately for signal A1 by means of parameter 306 and for signal A2 by means of parameter
316. The speed limitation is effective only when the respective signal is On.
Parameter 306/316 0 " Pedal controlled speed
1 " Limited to speed n9 (parameter 288) when signal is issued
2 " Limited to speed n11 (parameter 289) when signal is issued
The signals can be enabled or disabled separately for signal A1 by means of parameter 307 and for signal A2 by means of
parameter 317.
It is possible to select by means of parameter 308 for signal A1 and parameter 318 for signal A2, whether the signals
shall be activated with or without delay stitches.
Parameter 308/318 0 " Signal A1 / A2 activated without delay stitches
1 " Signal A1 / A2 activated with delay stitches
Separate stitch counts can be selected for signal A1 by means of parameter 309 and for signal A2 by means of parameter
319.
The switch-off moment for signals A1 and A2 can be set by means of parameter 320.
Parameter 320 0 " Signals effective until seam end
1 " Signals effective until pedal has been pressed to pos. 0 (neutral)
11.39 Signal “Machine Running“
Function with or without control panel Parameter
Mode "machine running" (LSG) 155
Switch-off delay for signal "machine running" (t05) 156
Parameter 155 = 0 Signal "machine running" Off.
Parameter 155 = 1 Signal "machine running" will be issued whenever the drive is running.
Parameter 155 = 2 Signal "machine running" will be issued whenever the speed is higher than 3000 RPM.
Parameter 155 = 3 Signal "machine running" will be issued whenever the pedal is not in position 0 (neutral).
Parameter 155 = 4 Signal "machine running" will be issued only after motor synchronization (one rotation at
positioning speed after power On).
The signal switch-off time can be delayed by means of parameter 156.
11.40 Signal Output Position 1
!
Transistor output with open collector
!
Signal whenever the needle is in the slot between position 1 and 1A
! Independent of sewing, thus also when turning the handwheel manually
!
Suitable e. g. for the connection of a counter
! An inverted signal is issued at socket ST2/20
11.41 Signal Output Position 2
!
Transistor output with open collector
!
Signal whenever the needle is in the slot between position 2 and 2A
! Independent of sewing, thus also when turning the handwheel manually
!
Suitable e. g. for the connection of a counter
!
An inverted signal is issued at socket ST2/21
