EFKA FP220A5911
69
! When using the V810 control panel, parameter 291 will automatically be set to slide-in strip "7" if 290 = 7.
!
When using the V820 control panel, parameter 292 will automatically be set to slide-in strip "5" if 290 = 7.
Function with control panel V810 V820
Tape cutter/Fast scissors at the start of the seam On lefthand arrow above key On 2 key 4 key
Tape cutter/Fast scissors at the seam end On righthand arrow above key On
Tape cutter/Fast scissors at the start and at the end both arrows above key On
of the seam On
Tape cutter/Fast scissors at the start and at the end both arrows above key Off
of the seam Off
The tape cutter signal can be influenced by parameter 020 in such a way that the signal remains on at the seam end and is
off when you start sewing again after some run-out stitches, which can be set by means of parameter 021. This action
serves as clamp.
Function with or without control panel Parameter
Clamp at the seam end (output ST2/27) On/Off (mode 7) (kLm) 020
Run-out stitches (ckL) of the clamp at the start of the seam (mode 7) or (ckL) 021
stitch counting after light barrier uncovered until tape cutter On (mode 15)
Output and Times for Tape Cutter
Function with or without control panel Parameter
Delay time for output M3 (ST2/27) tape cutter AH (kd3) 284
ON period for output M3 (ST2/27) tape cutter AH (kt3) 285
! Parameter 232 must be set at "0".
! The delay time for the tape cutter is usually set at "0".
Output and Times for Fast Scissors
Function with or without control panel Parameter
Delay time for output M3 (ST2/27) fast scissors AH1 (kd3) 284
ON period for output M3 (ST2/27) fast scissors AH1 (kt3) 285
Delay time for output M4 (ST2/36) fast scissors AH2 (kd4) 286
ON period for output M4 (ST2/36) fast scissors AH2 (kt4) 287
!
Parameter 232 must be set at "1".
! The delay times for "fast scissors" are usually set at "0".
11.26.3 Functions for Mode 15
Function without control panel Parameter
Count c1 and c2 On/Off LED 1/2 S2 key
Counts c3 and c4 On/Off LED 3/4 S3 key
Functions of sewing foot lifting On/Off LED 5/6 S4 key
Basic position 1 or 2 LED 7/8 S5 key
!
The tape cutter signal can be set separately for start and end counting.
!
When using the V820 control panel, parameter 292 will automatically be set to slide-in strip "5" if 290 = 15.
