Efka dc 1500 - Use in Accordance with Regulations; 3 Scope of Supply

EFKA FP220A5911
9
2.1 Use in Accordance with Regulations
The drive is not an independently operating machine, but is designed to be incorporated into other machinery. It must not
be put into service until the machinery into which it is to be incorporated has been declared in conformity with the
provisions of the EC Directive (Appendix II, paragraph B of the Directive 89/392/EEC and supplement 91/368/EEC).
The drive has been developed and manufactured in accordance with the relevant EC standards:
EN 60204-3-1:1990 Electrical equipment of industrial machines:
Particular requirements for industrial sewing machines, sewing units and sewing systems.
Operate the drive only in dry areas.
3 Scope of Supply
1 Direct current motor DC1500
1 Electronic control FP220A5911
- Power pack N201
1Actuator EB301A
1 Set of standard accessories B156 standard
consisting of: Plastic bag for B156
Documentation
or
1 Set of standard accessories B159 optional
consisting of: Bracket DC1500
Plastic bag for B159
Normal mounting foot
Belt guard, complete
Support + Mounting material
Documentation
Pulley A71-L
Adapter ring
1 Set of accessories Z53
consisting of: Pitman rod 400...700mm long
37-pin SubminD plug
Potential equalization cord
Bracket for fastening EB3..
Note
If there is no metallical contact between drive (motor) and machine head, the potential equalization cord supplied
with the unit is to be wired from the machine head to the terminal provided on the control box!
CAUTION
When selecting the installation site and the layout of the connecting cable, the Safety
Instructions in chapter 1 must be followed with no exceptions.
Particular attention should be paid to maintaining the proper distance from moving
parts!
