Efka dc 1500 - 8 Putting into Service; 9 Setting and Putting into Service with the Aid of the Fast Installation Routine (SIR)

EFKA FP220A5911
35
With SIR you can do the most important settings for initial operation with menu prompting.
For safety reasons, the menu must be executed point by point. This ensures correct setting of all important parameters.
The setting of other parameters is not affected.
Functions Parameter
Call-up of the Fast Installation Routine SIR (Sir) 500
Setting on the V810 control panel:
! Input code number 3112!
! Press the E key " The lowest parameter 2.0.0. appears at this level
! Select 500 " Parameter 5.0.0. is displayed
! Press the E key " Character [o] appears blinking
! Press the >> key " Parameter 2.9.0. appears (functional sequence “trimming operations”)
! Press the E key " Parameter value 05 appears
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 1.6.1. appears (direction of motor rotation)
! Press the E key " Parameter value 1 appears
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 2.7.2. appears (transmission ratio)
! Press the E key " Parameter value 100 appears
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 2.7.0. appears (type of position sensor)
! Press the E key " Parameter value 0 appears
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 4.5.1. appears (position 1 leading edge)
(position 1 trailing edge is
automatically set at 60°)
! Press the E key " Parameter value appears
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 4.5.3. appears (position 2 leading edge)
(position 2 trailing edge is
automatically set at 60°)
! Press the E key " Parameter value appears
! Press the +/- key " Parameter value can be changed
! Upon pressing the E key once more the program returns to parameter 290
! Press the P key twice " Exit SIR routine
Setting on the V820 control panel:
! Input code number 3112!
! Press the E key " The lowest parameter 2.0.0. appears at this level
! Select 500 " Parameter 5.0.0. is displayed
! Press the E key " Character [o] appears blinking
! Press the >> key " Parameter 290 FAm 05 appears (functional sequence “trimming operations”)
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 161 drE 1. appears (direction of motor rotation)
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 272 trr 100 appears (transmission ratio)
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 270 PGm 0 appears (type of position sensor)
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 451 appears (position 1 leading edge)
(position 1 trailing edge is
automatically set at 60°)
! Press the +/- key " Parameter value can be changed
! Press the E key " Parameter 453 appears (position 2 leading edge)
(position 2 trailing edge is
automatically set at 60°)
! Press the +/- key " Parameter value can be changed
! Upon pressing the E key once more the program returns to parameter 290
! Press the P key twice " Exit SIR routine
