EFKA FP220A5911
5
CONTENTS Page
11.14 Speed Depending on High Lift 59
11.14.1 Operating Mode of Speed Limitation Depending on High Lift 59
11.14.2 Setting the Speed Limitation Depending on High Lift with the V820 Control Panel 60
11.14.3 Setting the Speed Limitation Depending on High Lift with the V810 Control Panel 61
11.14.4 Potentiometer Adjustment on JUKI Machine Model LU-2210/LU2260 62
11.15 Speed Limitation n9 62
11.16 Speed Limitation n11 with Signal Output M10 / Flip-Flop 2 62
11.17 Disabling of Flip-Flop Functions at the Seam End 63
11.18 Bobbin Thread Monitor 63
11.19 Thread Trimming Operation 64
11.19.1 Thread Trimmer/Thread Wiper (Modes 0, 2, 3, 10, 14, 20 and 23) 64
11.19.2 Trimming Speed 64
11.19.3 Chainstitch Thread Trimmer (Modes 4, 5, 6, 21 and 24) 64
11.19.4 Chainstitch Machine Trimming Signal Times 65
11.20 Bag Sewing Machine Functions (Mode 5) 65
11.21 Stitch Lock Machine Functions (Mode 21) 65
11.22 Functions for Pegasus MHG-100 Machine (Mode 24) 66
11.23 Overlock Machine Functions (Mode 7) 66
11.23.1 Chain Suction Signal 66
11.23.2 Start and End Counts 67
11.24 Function of Output Signal M8 67
11.25 Function of Output Signal M11 68
11.26 Tape Cutter/Fast Scissors (Modes 6/7/15/16) 68
11.26.1 Functions for Mode 6 68
11.26.2 Functions for Mode 7 68
11.26.3 Functions for Mode 15 69
11.26.4 Functions for Mode 16 70
11.27 Manual Tape Cutter/Fast Scissors 71
11.28 Manual Stacker 72
11.29 Selection of Signals M8, M9 and M10 at the Start of the Seam 72
11.30 Seam with Stitch Counting 72
11.30.1 Stitches for Stitch Counting 72
11.30.2 Stitch Counting Speed 73
11.30.3 Seam with Stitch Counting When Light Barrier Is On 73
11.31 Free Seam and Seam with Light Barrier 73
11.32 Light Barrier 74
11.32.1 Speed after Light Barrier Sensing 74
11.32.2 General Light Barrier Functions 74
11.32.3 Reflection Light Barrier LS002 75
11.32.4 Light Barrier Monitoring 75
11.32.5 Automatic Start Controlled by Light Barrier 75
11.32.6 Light Barrier Filter for Knitted Fabrics 75
11.32.7 Functional Variations of the Light Barrier Input 76
11.33 Switching Functions of Inputs in1...i10 76
11.34 Software Debouncing of All Inputs 77
11.35 F1/F2 Function Key Assignment on the V810/V820 Control Panels 77
11.36 Functioning of Handwheel when Pressing a Key 78
11.37 Speed Limitation by means of External Potentiometer 78
11.38 Signals A1 and A2 79
11.39 Signal “Machine Running“ 81
11.40 Signal Output Position 1 81
11.41 Signal Output Position 2 81
11.42 Signal Output 512 Impulses per Rotation 82
11.43 Actuator 82
11.44 Audible Signal 83
