– Configure the weighing ranges
The weighing terminal is equipped with three different weighing range modes that specify
the weighing range used for:
NORMAL: Weight readings during normal display reading.
CALIBRATION: Weight readings during calibration and enhanced/high resolution weight
display.
PROTOCOL: Weight readings transferred using communication protocols.
Using the screens and menu system as described above in section Operate the menu system,
page 10 select the WEIGHING screen to configure the three weighing ranges:
– Perform coarse taring
To coarse tare the system follow these steps:
• Use the screens and menu system to select the COARSETARE screen.
• Press
F
to invoke the COARSETARE menu.
• Press to select the PERFORM COARSETARE menu item.
• Press to perform a coarse tare.
Please notice: Coarse taring should only be done when the system is empty!
