Sets the gross weight to zero and select Gross reading.
– Perform automatic dosing
To perform an automatic dosing, follow this procedure:
1. The desired Coarse and Fine setpoints must be entered. Use the key in the NORMAL
screen to select the DOSING screen. Then use the DOSING screen to enter the desired
setpoints.
2. To start a new dosing select the “Action: START DOSING” using the or key in the
DOSING screen and then press the key. Alternately start a new dosing by activating
the digital START input.
3. This will zero the net weight (automatic tare) and activate the digital COARSE and FINE
dosing outputs.
4. During dosing the COARSE output is active as long as the net weight does not exceed the
COARSE limit. An active COARSE output indicates dosing should be done at high speed
for the first part of the dosing, followed by slow speed for the final part of the dosing
where the COARSE output is deactivated.
5. When the net weight (positive or negative) reaches the FINE setpoint (possibly adjusted
by the afterflow correction) the FINE output will be deactivated and dosing is stopped.
6. Hereafter the COARSE and FINE outputs will remain deactivated until a new dosing is
started.
7. The dosed amount is automatically registered after the entered registration period, if
the registration period is different from 0 ms. In this case a registration can be made by
activating the REGISTRATION input. The result of the last registration can be read in the
NORMAL screen.
8. Following a registration the totals are updated and a possible new afterflow correction
may be calculated.
9. An ongoing dosing can be stopped prior to reaching the setpoint, by selecting the “Ac-
tion: STOP DOSING” using the or key in the DOSING screen and then pressing the
key. An ongoing dosing is also aborted if the weighing range is exceeded or if a load
cell error occurs.
10. The weighing terminal is ready for start of a new dosing.
