Introduction
This document describes the use of a 5024G LCD display terminal from Eilersen Electric,
when the software version listed on the front page is installed.
With this software, the terminal can perform automatic dosing (coarse/fine) using its digital
outputs and inputs. One digital output is used for coarse dosing and one digital output is
used for fine dosing, while a digital input is used for start of dosing and a digital input is used
for registration of dosed amount.
Installation
The following steps must be performed before the system is used:
• Install the load cells and check mechanical installation
• Optional: Connect digital outputs and digital inputs
• Connect and apply power
• Check software version
• Optional: Activation of Intelligent Setup feature
• Set up load cell configuration
• Power cycle the unit
• Configure weighing ranges
• Perform coarse taring
• Optional: Configure display, filtering, zero tracking range, stability requirement
• Optional: Corner calibration, system calibration, linearization
• Perform load check
Please notice: Perform a load check before the system is used to be sure that all require-
ments regarding accuracy, stability etc. are met before the system is used.
Please notice: If the Intelligent Setup feature is used, this will perform some of the subse-
quent points in the above list.
Details on the steps needed to install the system are explained below.
How to
– Perform basic operations
When the system is installed and power-up sequence has ended the display will look like this:
