Commissioning
7.3 Description of OSD menu
SCD 19102 / SMD 19102
58 Instruction Manual, 10/2011, A5E01588521A-004
Servicelevel 2 Function Adjustment/range Description
Serial bus Enable
Disabled
Default: Disabled
To configure a network of
several displays
This function is used to
interconnect several displays
so that they can all be
calibrated using a single
computer (connected to the
first display).
Note:
See the section "Serial
interface" (Page 34)
Bus address Slider from 0 ... 10
Default: 1
Definition of bus address for
display.
H-Scaler clip Slider from 0 ... 100 Supports adjustment to the
aspect ratio
The picture can be expanded
or compressed in the
horizontal direction.
Motion image improvement Active
Inactive
Default:
Interlaced signals: Active
Progressive signals: Inactive
Activation of motion image
improvement
• Undesirable comb effects
can be reduced in the
case of interlaced signals
with PAL and NTSC
resolutions connected to
the "VGA" and "DVI
Analog" signal inputs.
• Undesirable staircase
signals can be reduced in
the case of non-
interlaced signals
(progressive) of up to
60 Hz connected to the
"VGA" and "DVI Analog"
signal inputs.
Note:
See Chapter "Motion image
improvem
ent" (Page 80)
