Calibrating High Temperature PINIP™ Probes
Special thickness standards are supplied with F1 2 High
Temperature PINIP™ Probes - see page 37. These
thickness standards should be used in place of the
calibration standard in Step 1 of “Calibration adjustment
procedure” on page 26.
1. Place appropriate thickness standard over end of
PINIP™ probe.
2. Press CAL softkey.
3. Place probe on hot
c
surface and take a reading.
4. Lift probe and then replace on hot surface to take
second reading.
5. Repeat as necessary until reading is stable.
6. Press SET to accept value.
7. Remove thickness standard from end of PINIP™
probe.
8. Proceed with Step 2 - see page 27.
c. The temperature of the surface used for
calibration should be equal to the temperature of
the substrate being measured.
