17.6 Separate miniature ferrous probes
Probe Type
Minimum convex surface diameter
Minimum concave surface radius
Minimum sample diameter
Minimum access height
Minimum access width
Overall length (headroom)
F, St ra ig ht , 45 mm (1.77”)
1.5 mm (0.06”) 6.5 mm (0.26”) 3 mm (0.12”) 6 mm (0.24”) 150 mm (5.91”)
F, St ra ig ht , 150 mm (5.9”)
1.5 mm (0.06”) 6.5 mm (0.26”) 3 mm (0.12”) 6 mm (0.24”) 260 mm (10.24”)
F, 45°, 45 mm (1.77”)
1.5 mm (0.06”) 6.5 mm (0.26”) 3 mm (0.12”) 18 mm (0.71”) 7 mm (0.28”) 145 mm (5.71”)
F, 45°, 150 mm (5.9”)
1.5 mm (0.06”) 6.5 mm (0.26”) 3 mm (0.12”) 18 mm (0.71”) 7 mm (0.28”) 250 mm (9.84”)
F, 90°, 45 mm (1.77”)
1.5 mm (0.06”) 6.5 mm (0.26”) 3 mm (0.12”) 16 mm (0.63”) 7 mm (0.28”) 140 mm (5.51”)
F, 90°, 150 mm (5.9”)
1.5 mm (0.06”) 6.5 mm (0.26”) 3 mm (0.12”) 16 mm (0.63”) 7 mm (0.28”) 245 mm (9.64”)
