Elcometer 456 - Separate miniature non-ferrous probes

53
17.7 Separate miniature non-ferrous probes
Probe Type
Minimum convex diameter
Minimum concave radius
Minimum sample diameter
Minimum access height
Minimum access width
Overall length (headroom)
NF, Straight, 45 mm (1.77”)
3 mm (0.12”) 25 mm (0.98”) 4 mm (0.16”) 6 mm (0.24”) 150 mm (5.91”)
NF, Straight, 150 mm (5.9”)
3 mm (0.12”) 25 mm (0.98”) 4 mm (0.16”) 6mm (0.24”) 260 mm (10.24”)
NF, 45°, 45 mm (1.77”)
3 mm (0.12”) 25 mm (0.98”) 4 mm (0.16”) 18 mm (0.71”) 7 mm (0.28”) 145 mm (5.71”)
NF, 45°, 150 mm (5.9”)
3 mm (0.12”) 25 mm (0.98”) 4 mm (0.16”) 18 mm (0.71”) 7 mm (0.28”) 250 mm (9.84”)
NF, 90°, 45 mm (1.77”)
3 mm (0.12”) 25 mm (0.98”) 4 mm (0.16”) 16 mm (0.63”) 7 mm (0.28”) 140 mm (5.51”)
NF, 90°, 150 mm (5.9”)
3 mm (0.12”) 25 mm (0.98”) 4 mm (0.16”) 16 mm (0.63”) 7 mm (0.28”) 245 mm (9.64”)
