Electrolux EWM 3000 - Tub front, weight; Door, door glass, door rings, door hinge and locking hook

- 54 -
599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
10.1.6 Tub front, weight
Abb.: 15
17 Special screws
10.1.7 Door, door glass, door rings, door hinge and locking hook
The door is fastened to the front plate by the door hinge.
- Untighten the door hinge screws in order to separate the door from the front plate.
- To exchange door glass, locking hook, door hinge or one of the door rings,
remove the door ring screws.
Door hinge screws
Door ring screws
Abb.: 16
The tub front is screwed with 17 special screws with the rear side of the tub. If the weight must be
exchanged, the complete tub front has to be exchanged.
- Remove the worktop; instructions 10.1.1
- Disassemble the panel; instructions 10.1.2
- Untighten the front plate and the bellows; instructions 10.1.3
- Now you can unscrew the tub front (Fig. 15).
