- 47 -
599 51 13-50 EN
DGS-TDS-N 11.2004 C.D. © Electrolux
14.3 Legend
Legend wiring plan Legend circuit diagram
Short
name
Description Description in the wiring
plan
A Connection housing
C Selection switch b7/DW
E NTC - Sensor f30
E Main electronic
F In / Output electronic S17
H Lamp h11
HE Main earth
K Suppressor k5
L Floating switch f16.1 ; f16.2
MMotor m1
M Motor electronic PWM
N Pressure switch fs;fTR2;fTR1
N Pressure sensor p
P Recirculation pump m22
PPump m3
R Heating r1
V Valve s1;s2;s15
Z Door lock e4
b7 / DW Selection switch
e4 Door lock
E Main electronic
f16.1 f16.2 Floating switch
f 30 NTC - Sensor
fS Safety level
fTR1 ;
fTR2
Boil-dry protection
g 1 Tacho generator
h11 Lamp
k1 Direction of drum movement
k2 k3 Tapping / complete field
k 5 Suppressor
m 1 Main motor
m 3 Drain pump
m22 Recirculation pump
p Pressure sensor
r1 Heating element
s1 s2 s15 Valve
s17 In / Output electronic
