3.Technical Data
The E-ROBOT+3 Z Reciprocator is available, depending on operational area, in six versions with different
standard stroke heights.
3.1.Technical Data
*Vertical Axis
E-ROBOT+3 Z
1200
1500 1800 2100 2400 2700
Height
2,524 m
2,824 m 3,124 m 3,424 m 3,724 m 4,024 m
Stroke lenght
1,2 m
1,5 m 1,8 m 2,1 m 2,4 m 2,7 m
Belt
4,7 m
5,3 m 5,9 m 6,5 m 7.1 m 7.7 m
Order Code
A05RD01200+3-X A05RD01500+3-X A05RD01800+3-X A05RD02100+3-X A05RD02400+3-X A05RD02700+3-X
Stroke Speed 0.1 up to 0.6 m/s (6.0 up to 36.0 m/min.)
Acceleration 0.5-2.5 m/s²
Position detection with incremental pulse generator
*Horizontal Axis
E-ROBOT+3 X
Technical Values
Stroke lenght 1000 mm 1500 mm
Product Code A05X031000 A05X031500
Stroke Speed 0.06 up to 0.15 m/s (4.0 up to 8.0 m/min.)
Position Zero point selectable in both end positions
Position detection with incremental pulse generator
*Control Unit
E-DRIVE ZX02-E
Height 182 mm
Widht 220 mm
Depth 250 mm
Weight 3.34 kg
Product Code B08ZX02CM-E
3.2.Electrical Data
E-ROBOT+3 Z-Axis Reciprocator
Power supply 230 VAC (from control unit)
Tolerance ± 10%
Frequency 50/60 Hz
Protection Type IP54
Operating Temperature Range -10°C - +40°C
Max. Protection Surface Temperature 135°C
3.3.Sound Pressure Level
E-ROBOT+3 Z-Axis Reciprocator
Normal operation < 60 dB(A)
The sound pressure level was measured while the unit was in operation; measurements were taken at the most frequent oper-
ator positions and at a height of 1.7 m from the ground. The specied value is applicable only for this product itself and does
not take into account external noise sources or cleaning impulses. The sound pressure level may vary, depending on the product
conguration and space constraints.
