Electron E-ROBOT+3 Series - Set-up, Assembly, and Commissioning; Preparation for Start-up

13
4.Set-up, assembly and commissioning
WARNING:
If a free-standing reciprocator is not anchored firmly to the oor,
uncontrolled movement of the machine or insufficient stability can
cause injuries.
** Firmly anchor the reciprocator to the oor if it is not mounted to another axis of motion.
WARNING:
The movement of the reciprocator can cause injuries.
** Erect a protective fence around the reciprocator so that there is no danger of injury during nor-
mal operation.
DANGER:
Injuries can occur inside the protective fence due to the movement of the reciprocator!
** In order to enter the inner area, the door interlocks must be released by the control unit. This
release signal may only be activated by technical personnel.
DANGER:
Injuries can occur inside the protective fence due to the movement of the reciprocator!
** In order to enter the inner area, the door interlocks must be released by the control unit.
This release signal may only be activated by technical personnel.
Except for normal operation, all other operating modes must be set up by an authorized technical representative.
4.1.2 Setup and assembly
4.1.1 Preparation for start-up
Except for normal operation, all other operating modes must be set up by an authorized technical representative.
• Open The Base Top Covers
Consists of 2 parts. There are 2 bolts on the middle point of each cover. Use an 4 mm allen key.
WARNING:
Before connecting or switching on the reciprocator, read carefully these operating
instructions!
WARNING:
f a free-standing reciprocator is not anchored firmly to the oor, uncontrolled movement of
the machine or insufficient stability can cause injuries.
** Firmly anchor the reciprocator to the oor if it is not mounted to another axis of motion.
WARNING:
The movement of the reciprocator can cause injuries.
** Erect a protective fence around the reciprocator so that there is no danger of injury during
normal operation.
