7.E-DRIVE ZX02-E Reciprocator Control Unit and Setting
Display No Display Name
B1
Main Switch (ON-OFF)
B2
Up Key
B3
Down Key
B4
Adjustment Led
B5,B6,B7,B8,B9
Segment Buttons
K10
Rotary Adjustment Knob
B11
Reset Button
B12
Axis Start/Stop Button
B13
Menu Button
B14
Axes Active/Passive Button
7.1. Front Panel and Input Buttons
