15.
Fault Chart
Error Solution
The toothed belt rides up
on the anged wheel
1. Loosen the motor and move it manually into the appropriate
opposite direction.
2. The toothed belt may not ride up on the anged wheel at
the whole driveway as well as in the reversal points.
Reciprocator and carriage plate
are waggling
1. Check the connecting bolts between reciprocator, carriage
plate and the E-ROBOT+3 Z Horizontal Motion Unit car- riage for
tightness.
2. Adjust the counter rollers without clearance by the corre-
sponding screws on the running wheel bearing/guide wheel bear-
ing (see also the spare parts list).
3. In no case press the counter rollers, otherwise they wear
quickly!
WARNING:
Faults are to be corrected by trained personnel only!
