1.3.8 Special safety regulations for E-ROBOT ZX02-EX Reciprocator
• The E-ROBOT+3 Z Reciprocator may only be switched on and operated after a careful reading of this manual and
E-DRIVE ZX02-E’s manual. Incorrect operation of the axes control unit can lead to accidents, malfunctions or
damage to the plant.
• Attention, the power of the reciprocator is very much stronger than that of a human being!
All axes must be secured against access during operation (see local regulations).
Never stand under the Z carriage when the vertical axis is not operating!
• The plugs and sockets of the axes control unit and E-ROBOT+3 Z should only be unplugged when the power
supply is disconnected.
• The connecting cables between the control unit and the reciprocator must be laid in such a way, that they cannot
be damaged during axes operation. Please observe the local safety regulations!
• The maximum upper stroke limit of the reciprocator must always be set with reference to the maximum height of
the booth gun slots. If an incorrect (too high) stroke limit is set, this can lead to damage to the reciprocator and/
or the booth!
WARNING:
During a test run, it must be guaranteed that the unit is not
damaged by the test! In particular, the limitations of the stroke
range have to be observed (for further information, see chapter
“Setting the upper mechanical stop”)!
• When repairing the reciprocator, both the reciprocator control unit and the reciprocator must be disconnected
from the mains according to the local safety regulations!
• Repairs may be done only by authorized Electron service. Unauthorized conversions and modifications can lead
to injuries and damage to the equipment. The Sistem Teknik Makina A.Ş. guarantee would no longer be valid.
• Only original Gema spare parts should be used! The use of spare parts from other manufacturers will invalidate
the Electron guarantee conditions!
• We point out that the customer himself is responsible for the safe operation of the equipment. Sistem Teknik
Makina A.Ş. is in no way responsible for any resulting damage.
1.4. About this manual
This operating manual contains all the important information you require for the working with the ZX02-D
Reciprocator. It will safely guide you through the start-up process and give you references and tips for the
optimal use of your new powder coating system. Information about the function mode of the individual system com-
ponents - booth, gun control unit, manual gun or powder injector - should be referenced to their corresponding docu-
ments.
DANGER:
Working without operating instructions
Working without operating instructions or with individual pages from the operating
instructions may result in damage to property and personal injury if relevant safety
information is not observed.
** Before working with the device, organize the required documents and read the section
“Safety regulations”.
** Work should only be carried out in accordance with the instructions of the relevant
documents.
** Always work with the complete original document.
