NOTE:
Reciprocator enclosing dimensions are given so that two single vertical axes fit in the same case.
NOTE:
1) When you order an E-ROBOT+3 Z vertical axis reciprocator, 4 qty ‘’ CLAMP ROBOT BODY
Ø40 ‘’ (Product Code: B07EH50907) is sent.
2) Other than that, other Clamps and poles must be ordered separately. (Page-48).
3) If you want to buy the E-ROBOT+3 X horizontal axis reciprocator separately from the system,
we send you a set (Product Code: B08ZX02YM) so that you can integrate it into the E-ROBOT+3 Z
vertical axis reciprocator system.
Ordering steps;
1. Select which of the tables marked 1, 2, 3 and 4 above ts the system you want to order.
2. All the products you need to order are described in the “Products” section.
3. Each product’s own options are selected from the “Types” column. Order can be placed with the Order code
next to it.
4. When ordering, do not forget to specify the number of quantity in the table.
Example;
You want to order 2 pcs 1800 stroke vertical axis robot systems, standing opposite each other in the booth.
In that case, we are looking at table number 3. You need to order 4 products in this table separately.
-Product: E-Robot+3 Z , Type: 1800 stroke , Code: B07RG0303 , 2 pcs
+
-Product: E-DRIVE ZX02-E , Code: B08ZX02CM-E , 1 piece
+
-Product: E-DRIVE ZX02-E RECIPROCATOR SIGNAL CABLE, Type: 20 MT , Code: B08ZX02SC-E20 , 2pcs
+
-Product: E-DRIVE ZX02-E RECIPROCATOR POWER CABLE, Type: 20 MT , Code: B08ZX02PC-E20 , 2pcs
4) For dual Reciprocator systems;
Systems Products Types Codes Qty
Double Axis
Reciprocator
System
E-ROBOT+3 Z
1200 Stroke B07RG0301
2
1500 Stroke B07RG0302
1800 Stroke B07RG0303
2100 Stroke B07RG0304
2400 Stroke B07RG0305
2700 Stroke B07RG0306
E-ROBOT+3 X
1000 Stroke / 1500 Stroke A05X031000 / A05X031500
2
E-DRIVE ZX02-E N/A B08ZX02CM-E 1
E-DRIVE ZX02-E RECIPROCATOR
SIGNAL CABLE
10 MT B08ZX02SC-E10
2
15 MT B08ZX02SC-E15
20 MT B08ZX02SC-E20
25 MT B08ZX02SC-E25
E-DRIVE ZX02-E RECIPROCATOR
POWER CABLE
10 MT B08ZX02PC-E10
2
15 MT B08ZX02PC-E15
20 MT B08ZX02PC-E20
25 MT B08ZX02PC-E25
